3 Circuit Track Lighting
The 3 circuit track is an advancement from our single circuit track and has great functionality insofar as fittings on the track can be independently illuminated. The single circuit track is a system which, when switched on, all lights come on at the same time - you cannot control which fittings are on and which are off. The beauty of the 3 circuit track system is that it has 3 live wires and one neutral, this creates the possibility to have up to three separate circuits on one length of track, each with the ability to be individually controlled by one 3-way switch. This provides plenty of flexibility of the distribution of your light - perfect for retail point of sale or for residential properties where track lighting is the only lighting.
Ideal for large kitchen areas, dining areas or commercial and retail spaces, where a large configuration of track is installed, but not all lighting is needed to be illuminated at once. When you add a light fitting to the track you can determine which of the three circuits it is on by moving the dial to the corresponding circuit number. This fantastic system allows fine-tuning of light and unlimited changing of position, which is the perfect solution for ever changing display environments.
Available in varying lengths with a choice of three finishes this is a highly customisable system which allows you to do more with your space. The track can be cut to the required length for the project with a mitre saw or junior hacksaw. Not to mention the plethora of lamp heads and fittings! Additional components allow you to not only have straight runs but also turn corners and connect runs together, suspend the track or mix it up with spot heads and pendants by using the 5kg pendant adapter.
Complex Joints for 3-Circuit Lighting Tracks – Bends, T and X Connections
17 Options£14.40
Compatible 3 Circuit Lighting Track - Ceiling Fixed or Wire Suspended
13 Options£26.40
Simple Joints for 3-Circuit Lighting Tracks – Feed-In, & Straight Connections
17 Options£3.50
Grey Bullet Style Light Pendant - Use with a Track Adapter
12 Options£29.50
Budget-Friendly GU10 Spotlight for 3-Circuit Mains Track
2 Options£32.00
40cm Black Dome Pendant for Mains Track - Prewired for use on Signature & 3-Circuit Track
2 Options£240.00
Reduced Glare Track Spotlight For GU10 Mains Lamps - Black or White
2 Options£33.50
Enclosed Conical GU10 Spot for 3- Circuit Track - Metal Finishes
4 Options£39.50
Reduced Glare Track Spotlight for GU10 Mains Lamps - Brass or Gunmetal
2 Options£39.50
Sleek Design LED Track Pencil Spot for 3 Circuit Track
2 Options£52.80
COB Track Spotlight - 15 watt 1300 Lumens 3000k or 4000k
4 Options£45.90
High Powered LED with Adjustable Beam Track Head
8 Options£82.70
GU10 Lamp Base Adjustable Spot for 3 Circuit Track
6 Options£41.60
15W COB LED Commercial Track Spot - Adjustable
2 Options£45.00
Black 8w Low Glare COB Track Spot Light - Dimmable LED Spotlight for 3-Circuit Tracks
£51.30
White 8W COB Track Spot Light - Dimmable LED Spotlight for 3-Circuit Tracks
£51.30
Black 30W track spot with COB LED, ideal forshops and showrooms.
£52.10
High Output COB LED Cylinder Track Light – 30W, Warm White, 38° Beam
£52.10
White 30W track spot with COB LED - Ideal for Shops and Showrooms
£52.10
Modern White COB LED Cylinder Track Spotlight - 30W Warm White, 38° Beam Angle
£52.10
30w COB LED Track Spot - 2700 Lumens, 38° Beam, Global 3-Circuit Track Compatible
4 Options£57.90
Linear LED Track Light Fixture for 3 Circuit Track - Opal Diffuser
6 Options£72.00
Compatability
Erco and Zumtobel spots can generally be used with this 3-circuit lighting track.
Many UK and European lighting manufacturers, including Erco and Zumtobel, design their fixtures to be compatible with the EUTRAC profile. This ensures compatibility with a wide range of track systems, including Global, Nordic, LTS, Unipro, SLV, Thorn, Ivela, Staff, iGuzzini, Nokia, and Hoffmeister.
However, there are some exceptions to be aware of:
- DALI Fixtures: These are often not compatible with standard 3-circuit tracks.
- Older Fixtures: Products designed more than 30 years ago may not align with modern profiles.
- Single or Two-Circuit Fixtures: Fixtures designed specifically for single or two-circuit tracks will not work with 3-circuit systems.
If you're unsure about the compatibility of a specific fixture, we recommend checking the manufacturer's technical specifications or contacting us for further assistance.
